HBM / HLC / Bending / beam Load Cell

HBM / HLC / Bending / beam Load Cell

These load cells are designed to be precise, robust, and adaptable, making them perfect for a wide range of uses, from tank and platform scales to level monitoring.

  • Ensuring precise results with OIML accuracy classes D1, C3, C4, C6 and NTEP 5000 IIIM
  • Maximum capacities ranging from 110 kg to 10 tons, the HLC ensures reliable and precise measurements.
  • Optimized for the parallel connection of multiple load cells
  • Stainless steel construction and up to IP68/IP69K degree of protection, ensure durability even in harsh environments.

NEW: Now available as HLCi with integrated intelligent IO-Link or analog option (4 … 20 mA or 0 … 10 V)

Categories: ,
Tag:

Description

Type HLC Load Cells: Robust Weighing up to Accuracy Class C6

HLC load cells are perfectly suited for use with any type of tank, batching or platform scales as well as for level monitoring – and are used by market leaders. Their 6-wire configuration allows for precise measurement results up to accuracy class C6 per OIML R60. The particularly robust HLC load cells are available in standard dimensions and can be easily integrated and quickly adapted to the required maximum capacities ranging from 110 kg to 10 tons. In addition, versions with IP69K degree of protection and explosion proof IECEx-ATEX designs are available. HLC is available as:

  • Version B1 (with counterbore thread and IP68 degree of protection)
  • Version B2 (with counterbore thread and IP68/IP69K degree of protection)
  • Version B2-P (with M12x1 device plug)
  • Version A1 (with through-hole thread and IP68 degree of protection)
  • Version HLCi (integrated IO-Link or analog option (4 … 20 mA or 0 … 10 V)
  • Version F2 (with blind hole, 90˚ countersink and IP68 degree of protection)
  • Optional explosion-proof version
  • Also available as HLC/M weighing module (with special mechanical protection of the load cell).

New – HLCi: Utilize IO-Link automation in your application

  • Industry standard IO-Link Interface
  • Easy to integrate in your ecosystem
  • M12 4-Pin Connector
  • Smart functions (preprocessing of data, self-monitoring and warnings)

Monitor your load cell in real time



HLC

Precise

  • Accuracy classes up to C6 according to OIML
  • Robust 6-wire configuration for compensation of resistance variations
  • Optimized for the parallel connection of multiple load cells
  • Legal-for-trade weighing system up to 6,000 divisions

High accuracy for virtually any application, through to the legal-for-trade weighing system



Robust

  • Load cell made of stainless steel
  • Extremely resistant to chemical substances thanks to optional TPE-0 cable sheath
  • IP68/IP69K degree of protection ensures durability under permanent humidity and high-pressure-conditions

Robust and precise also in hash environments thanks to ruggedized design



Flexible

  • Different maximum capacities are available: 110 kg, 220 kg, 550 kg, 1.1 t, 1.76 t, 2.2 t, 4.4 t, and 10 t
  • Metrological approvals: OIML, NTEP (USA), NMIA (Australia)
  • Explosion-proof versions are available (IECEx/ATEX, FM (USA))
  • All product versions have identical dimensions and low height
  • Cable can be cut to length owing to the 6-wire configuration
  • Different cable types and lengths available

Variable and individual use due to standard dimensions and different maximum capacities

Now available: HLC-P with a built-in connector plug

The top-selling HLC bending beam load cells are now optionally available with a built-in M12 connector in the HLC-P variant. This means that users are more flexible in their cable selection, and that cables can be exchanged much faster and do not require the disassembly of the machine.

The built-in plug is available for nominal loads between 220 kg and 4.4 t. The dimensions of the HLC-P load cell are compatible to other HLC variants, so all accessories, such as loading feet or base plates, can be used with the new version.

HLC versions and accessories

Available as:

  • Version B1 (standard version)
  • Version B2 (special protection)
  • Version A1 (with through-hole thread)
  • Version F2 (with blind hole)
  • Optional explosion-proof version
  • Also available as HLC/M weighing module (with special mechanical protection of the load cell).

Extensive accessories such as loading feet or rubber-metal-elements meeting the highest requirements in terms of durability.

For more information please refer to the data sheet.

All models

Code Maximum capacity Accuracy class Degree of protection Minimum verification interval (Vmin) Special feature
1-HLCA1C3/1.1T-1 1.1 t C3 IP68 99 g None
1-HLCA1C3/1.76T-1 1.76 t C3 IP68 176 g None
1-HLCA1C3/2.2T 2.2 t C3 IP68 220 g None
1-HLCA1C3/4.4T 4.4 t C3 IP68 440 g None
1-HLCA1C3/220KG-1 220 kg C3 IP68 22 g None
1-HLCA1C3/550KG-1 550 kg C3 IP68 49.5 g None
1-HLCA1D1/1.1T-1 1.1 t D1 IP68 313.5 g None
1-HLCA1D1/1.76T-1 1.76 t D1 IP68 501.6 g None
1-HLCA1D1/2.2T 2.2 t D1 IP68 627 g None
1-HLCA1D1/4.4T 4.4 t D1 IP68 1254 g None
1-HLCA1D1/220KG-1 220 kg D1 IP68 62.7 g None
1-HLCA1D1/550KG-1 550 kg D1 IP68 156.75 g None
1-HLCB1C3/1.1T-1 1.1 t C3 IP68 99 g None
1-HLCB1C3/1.1TA 1.1 t C3 IP68 99 g None
1-HLCB1C3/1.76T-1 1.76 t C3 IP68 176 g None
1-HLCB1C3/1.76TA 1.76 t C3 IP68 176 g None
1-HLCB1C3/2.2T 2.2 t C3 IP68 220 g None
1-HLCB1C3/4.4T 4.4 t C3 IP68 396 g None
1-HLCB1C3/110KG-1 110 kg C3 IP68 9.9 g None
1-HLCB1C3/110KGA 110 kg C3 IP68 9.9 g None
1-HLCB1C3/220KG-1 220 kg C3 IP68 22 g None
1-HLCB1C3/220KGA 220 kg C3 IP68 22 g None
1-HLCB1C3/550KG-1 550 kg C3 IP68 49.5 g None
1-HLCB1C3/550KGA 550 kg C3 IP68 49.5 g None
1-HLCB1C4/1.1T 1.1 t C4 IP68 99 g None
1-HLCB1C4/220KG 220 kg C4 IP68 22 g None
1-HLCB1C4/550KG 550 kg C4 IP68 49.5 g None
1-HLCB1C6/1.1T 1.1 t C6 IP68 110 g None
1-HLCB1C6/220KG 220 kg C6 IP68 22 g None
1-HLCB1C6/550KG 550 kg C6 IP68 49.5 g None
1-HLCB1D1/1.1T-1 1.1 t D1 IP68 313.5 g None
1-HLCB1D1/1.76T-1 1.76 t D1 IP68 501.6 g None
1-HLCB1D1/2.2T 2.2 t D1 IP68 627 g None
1-HLCB1D1/2T 2 t D1 IP68 570 g None
1-HLCB1D1/4.4T 4.4 t D1 IP68 1254 g None
1-HLCB1D1/10T 10 t D1 IP68 2850 g None
1-HLCB1D1/110KG-1 110 kg D1 IP68 31.35 g None
1-HLCB1D1/220KG-1 220 kg D1 IP68 62.7 g None
1-HLCB1D1/550KG-1 550 kg D1 IP68 156.75 g None
1-HLCB2C3/1.1T3 1.1 t C3 IP68/IP69K 99 g None
1-HLCB2C3/1.1T-1 1.1 t C3 IP68/IP69K 99 g None
1-HLCB2C3/1.76T-1 1.76 t C3 IP68/IP69K 176 g None
1-HLCB2C3/2.2T 2.2 t C3 IP68/IP69K 220 g None
1-HLCB2C3/4.4T 4.4 t C3 IP68/IP69K 440 g None
1-HLCB2C3/110KG-1 110 kg C3 IP68/IP69K 9.9 g None
1-HLCB2C3/220KG-1 220 kg C3 IP68/IP69K 22 g None
1-HLCB2C3/550KG3 550 kg C3 IP68/IP69K 49.5 g None
1-HLCB2C3/550KG-1 550 kg C3 IP68/IP69K 49.5 g None
1-HLCB2C4/1.1T 1.1 t C4 IP68/IP69K 99 g None
1-HLCB2C4/220KG 220 kg C4 IP68/IP69K 22 g None
1-HLCB2C4/550KG 550 kg C4 IP68/IP69K 49.5 g None
1-HLCB2C6/1.1T 1.1 t C6 IP68/IP69K 99 g None
1-HLCB2C6/220KG 220 kg C6 IP68/IP69K 22 g None
1-HLCB2C6/550KG 550 kg C6 IP68/IP69K 49.5 g None
1-HLCB2D1/1.1T-1 1.1 t D1 IP68/IP69K 313.5 g None
1-HLCB2D1/1.76T-1 1.76 t D1 IP68/IP69K 501.6 g None
1-HLCB2D1/220KG-1 220 kg D1 IP68/IP69K 62.7 g None
1-HLCB2D1/550KG-1 550 kg D1 IP68/IP69K 156.75 g None
1-HLCF2C3/1.1T-1 1.1 t C3 IP68 99 g None
1-HLCF2C3/1.76T-1 1.76 t C3 IP68 176 g None
1-HLCF2C3/220KG-1 220 kg C3 IP68 22 g None
1-HLCF2C3/550KG-1 550 kg C3 IP68 49.5 g None
K-HLC 110 kg, 220 kg, 550 kg, 1.1 t, 1.76 t, 2.2 t, 4.4 t, 10 t D1 IP68 31.35 g, 62.7 g, 156.75 g, 313.5 g, 501.6 g, 627 g, 1254 g, 2850 g, 9.9 g, 22 g, 49.5 g, 99 g, 176 g, 220 g, 440 g None
K-HLC-P 220 kg, 550 kg, 1.1 t, 1.76 t, 2.2 t, 4.4 t C3 IP68/IP69K 22 g, 49.5 g, 99 g, 176 g, 220 g, 440 g Plug connector
K-HLCB2 110 kg, 220 kg, 550 kg, 1.1 t, 1.76 t, 2.2 t, 4.4 t C3 IP69K 9.9 g, 22 g, 49.5 g, 99 g, 176 g, 220 g, 440 g None

Specifications

HLC
Type Bending beam
Application Animal Weighing (Lifestock), Dynamic Filling / Dosing, Static Filling/Dosing, Silo/Tank weighing
Maximum capacity 1.1 t, 1.76 t, 2.2 t, 4.4 t, 220 kg, 550 kg, 110 kg, 10 t, 2 t
Accuracy class C3, D1, C4, C6
Degree of protection IP68, IP68/IP69K, IP69K
Minimum verification interval (Vmin) 99 g, 176 g, 220 g, 440 g, 313.5 g, 22 g, 49.5 g, 627 g, 1254 g, 501.6 g, 62.7 g, 156.75 g, 9.9 g, 396 g, 110 g, 2850 g, 31.35 g, 570 g
Material Stainless steel with protective coating
Certification OIML, NTEP (US), ATEX/IECEx
Maximum platform size n/a
Output signal Passive (mV/V)
Special feature None, Plug connector
