| Rated Capacity (Cn) |
Static: 10 t / Dynamic: 5 t |
| Combined Error |
± 0.1 % Cn |
| Temperature Effect on Zero |
± 0.005 % Cn / °C |
| Temperature Effect on Sensitivity |
± 0.005 % Cn / °C |
| Creep Error (30 min.) |
± 0.03 % Cn |
| Accuracy Class |
– |
| Maximum Capacity (Emax) |
– t |
| Max. Number of Load Cell Intervals (nmax) |
– d (OIML) |
| Minimum Verification Interval (vmin) |
– t |
| Z = Emax / (2 × DR) |
– |
| Nominal Range of Excitation Voltage |
1 … 15 V |
| Rated Output at Cn |
0.88 ± 0.01 mV/V |
| Zero Balance |
±1 %Cn |
| Input / Output Resistance |
385 ±10 / 350 ±3 Ω |
| Insulation Resistance |
2,000 MΩ / 50 V |
| Compensated Temperature Range |
-10 … +50 °C |
| Service Temperature Range |
-20 … +60 °C |
| Safe Dynamic Loading |
50 %Cn |
| Safe Load Limit |
150 %Cn |
| Ultimate Overload |
200 %Cn |
| Tightening Torque |
– Nm |
| Protection Class |
IP67 (EN 60529) |
| Material – Measuring Body |
Nickel plated steel |
| Material – Cable Gland |
– |
| Material – Cable Sheath |
– |
| Cable Length |
10 m |
| Net Weight |
9.5 kg |
