| Rated output |
1mV/V ±30% (20kN:1.5mV/V ±20%) |
| Nonlinearity |
Up to ±1%R.C. (20kN: Up to ±2%R.C.) |
| Hysteresis |
Up to ±1%R.C. (20kN: Up to ±2%R.C.) |
| Repeatability |
Up to ±1%R.C. |
| Zero balance |
Up to ±5%R.C. |
| Temperature effect on zero balance |
±0.5%R.C./10°C |
| Temperature effect on load |
±0.5%R.C./10°C |
| Safe overload rating |
120%R.C. |
| Temperature compensation range |
−5–50°C (No condensation or freezing) |
| Safe temperature range |
−10–60°C (No condensation or freezing) |
| Input terminal resistance |
350Ω±2.5% |
| Output terminal resistance |
350Ω±2.5% |
| Recommended excitation voltage |
5V or less |
| Maximum excitation voltage |
7V |
| Insulation resistance |
1000MΩ or more (DC 50V) |
| IP Rating |
Equivalent to IP60 (Main body only) (Note 1) |
| Cable |
φ1.7 4-core Shielded cable (FEP-PVC-YI) 3m, directly-connected |
