| Rated output |
1.5mV/V±2% |
| Nonlinearity |
±0.1%R.C. |
| Hysteresis |
±0.1%R.C. |
| Repeatability |
±0.1%R.C. |
| Zero balance |
±5%R.O. |
| Temperature effect on zero balance |
±0.05%R.C./10°C |
| Temperature effect on load |
±0.05%R.C./10°C |
| Safe overload rating |
200%R.C. |
| Temperature compensation range |
−10–60°C (No condensation or freezing) |
| Safe temperature range |
−15–75°C (No condensation or freezing) |
| Input terminal resistance |
350Ω±2% |
| Output terminal resistance |
350Ω±2% |
| Recommended excitation voltage |
1~10V |
| Safe excitation voltage |
15V |
| Insulation resistance |
1000MΩ or more |
| IP rating |
Equivalent to IP65 (Note 1) |
| Cable |
φ8-4-core Shielded cable (CESV-B) 10m Non-stranded wire |
