Loadstar Sensors RSB2 Button Load Cell

Loadstar Sensors RSB2 Button Load Cell

RSB2 button load cells are excellent for measuring compression loads or push forces with very high accuracy and stability with time and temperature. They have four threaded mounting holes on the base to make it easy to attach it to your particular assembly. They are available in 25 kg, 50 kg, 100 kg, 250 kg, 500 kg and 1000 kg capacities. For higher capacities, please take a look at our RSB1 or RAL1 load cells. For smaller sizes see REB5 or RSB5 load cells.
Category:
Tag:
Brand:

Description

RSB2 Button Load Cell

Highlights



  • Capacities
    RSB2 Button load cells are available in 25 kg, 50 kg, 100 kg, 250 kg, 500 kg and 1000 kg capacities. See RSB2 for lower capacities. See REB5 and RSB5 for smaller sizes.

  • Calibration Mode
    Button load cells can be used only for Compression measurements. If you need to measure tensile forces then use RSB3, RAS1, RAL1 load cells.

  • Accuracy Class & Compensated Temperature Range
    +/- 0.02% to +/- 0.05% from -10C to 40C

  • Construction and Use
    Raised boss at center for applying compressive loads. Rugged strain relief provided on cable egress for improved reliability.

  • UART/USB Output
    Use DI-100U with UART output to connect with Arduino or other microprocessors. Or use DI-100U/DI-1000U/DI-400U USB load cell interfaces to connect with PCs via USB.

    Wireless Output
    Wireless output via XBee (802.15.4) Industrial Strength wireless or WiFi or BLE for easy connectivity with PCs, Tablets and SmartPhones

    Analog Output
    Analog output via 0-5V DC or 4-20 mA output for easy input to DAQ or PLC

    Customize
    Call us for larger capacities or other unique needs. We can custom build them to order as needed.

rsb2
