Load cell for the measurement of static and dynamic loads in TENSION
Nominal Load from 20 tons to 100 tons
Linearity: 0,10%
Output: 2mV/V
on request
Dimensions [mm]
| CODE | LOAD | A | B | C | D | E | F |
|---|---|---|---|---|---|---|---|
| CD20020TC25 | 20 t | 102 | 280 | 78 | 60 (1) | 50 | ~140 |
| CD20030TC25 | 30 t | 102 | 280 | 78 | 60 (1) | 50 | ~140 |
| CD20050TC25 | 50 t | 130 | 350 | 88 | 73 (2) | 75 | ~171 |
| CD20075TC25 | 75 t | 130 | 350 | 88 | 73 (2) | 75 | ~171 |
| CD200100TC25 | 100 t | 130 | 350 | 88 | 73 (2) | 75 | ~171 |
(1) Utilizzare solo con perno Ø 57 mm / Use only with Ø 57 mm pivot
(2) Utilizzare solo con perno Ø 70 mm / Use only with Ø 70 mm pivot
Technical Data
| ACCURACY CLASS | 0.1% |
| LINEARITY and HYSTERESIS | 0.1% |
| NOMINAL LOAD | 20 t – 30 t 50 t – 75 t – 100 t |
| TEMPERATURE EFFECT (10 °C) | a) on zero: ≤ ±0.028% b) on sensitivity: ≤ ±0.008% |
| NOMINAL SENSITIVITY CALIBRATION TOLERANCE | 2 mV/V ≤ ±0.1% |
| INPUT RESISTANCE | 420 ± 20 Ω |
| OUTPUT RESISTANCE | 350 ± 2 Ω |
| INSULATION RESISTANCE | > 5 GΩ |
| ZERO BALANCE | ≤ ±1% |
| RECOMMENDED SUPPLY VOLTAGE | 10 V |
| NOMINAL SUPPLY VOLTAGE | 1 – 15 V |
| MAX. SUPPLY VOLTAGE | 18 V |
| MECHANICAL LIMIT values (referred to nominal load) | a) minimum load: 0% b) service load: 120% c) max permissible load: 150% d) breaking load: >200% e) max transverse load: 50% |
| REFERENCE TEMPERATURE | +23 °C |
| TEMPERATURE NOMINAL RANGE | -10 / +40 °C |
| WORKING TEMPERATURE | -20 / +70 °C |
| STORAGE TEMPERATURE | -20 / +80 °C |
| WEIGHT | ~10 kg ~19 kg |
| PROTECTION CLASS (EN 60529) | IP65 |
| EXECUTION MATERIAL | Acciaio Inox / Stainless Steel |
| CONNECTOR | MIL-C-5015 7 poles male |
Electrical Connections
PVC 105°C shielded cable, Ø5.2mm with 6 tinned Ø0.25mm2 conductors.
Shield connected to the body of the load cell.
