Compression Load Cell WTS
WTS is low profile single-ended shear beam load cell, designed for floor scales, pallet scales, tank, hopper and silo weighing applications. Made from high quality alloy steel (optional stainless steel) and with industry highest standards, WTS is the good choice for heavy-duty and harsh environments.
Applications
- Floor scales
- Pallet scale
- Tank, hopper weighing ,· High stability· The structure is highly low· The comprehensive accuracy is high· Anti-interference signals are stable· Quality alloy steel with nickel plating· widely used in electronic belt scale,packaging scale, filling scale In the equal weighing equipment.And the
automation equipment field and testing Trial field.
PECIFICATIONS
| Rated Capacity | 0.1~600T |
| Full Scale Output | 2.0mV/V ± 0.1% / 3.0mV/V ± 0.1% |
| Zero Balance | ± 0.02mV/V |
| Non-linearity | < ± 0.023%F.S |
| Repeatability | < ± 0.030%F.S |
| Hysteresis Error | < ± 0.030%F.S |
| Creep in 30 minutes | < ± 0.030%F.S |
| Input Resistance | 775Ω ±10Ω |
| Output Resistance | 702Ω ± 2Ω |
| Recommended Excitation | 10V (15V Maximum) |
| Insulation Resistance | > 5000MΩ (50V DC) |
| Temperature Effect on Sensitivity | < ±0.0012% of Cn/k |
| Temperature Effect on Zero Balance | < ± 0.0040% of Cn/k |
| Working Temperature Range | -30°C to 70°C/-20°F to 160°F |
| Storage Temperature Range | -50°C to 85°C/-58°F to 185°F |
| Safe Overload | 150%F.S |
| Breaking Overload | 300%F.S |
| Seal Type | Glue / Welded sealed |
| IP Rating | IP67 / IP68 |
