HARDY / ST03C-SS series PERFORMANCE S-BEAM

설명

ST03C – C2® Stainless Steel S-Beam Tension Load Cell (50 kg to 10 mt)

The Hardy Process Solutions ST03C tension type stainless steel sensor is designed for hanging vessels, hoppers, filling machinery and process control.

ST03C tension load cells feature an IP67 rating, and improved potting which makes them suitable for use in industrial environments. They are available in capacities from 100 lb to 10 tons and are accurate load cells even in high capacities..

This versatile tension load cell can be mounted standalone or using threaded rods. It can also be used in compression applications

S-BEAM
MODEL#	CAPACITY kg/mt lbs
ST03C-SS-50KG	50 Kg	110 Lbs.
ST03C-SS-100KG	100 Kg	220 Lbs.
ST03C-SS-250KG	250 Kg	550 Lbs.
ST03C-SS-500KG	500 Kg	1,100 Lbs.
ST03C-SS-1MT	1mt	2,200 Lbs.
ST03C-SS-2.5MT	2.5 mt	5,500 Lbs.
ST03C-SS-5MT	5 mt	11,000 Lbs.
ST03C-SS-7.5MT	7.5 mt	16,500 Lbs.
ST03C-SS-10MT	10 mt	22,000 Lbs.

SPECIFICATIONS
Rated Output (ES)	3.0 ± 0.008 mV/V
Combined Error	<±0.02 % R.O.
Zero Balance	<±1.0 % R.O.
Creep @ 30 Min.	<±0.016 % R.O.
Temp Effect Output	<±0.015 % R.O./C
Temp Effect Sensitivity	<±0.011 % R.O./C
Input Resistance	430 ± 50
Output Resistance	351 ± 2.0 ohm
Insulation Resistance	>5000 Mohm
Max # Verification Int.	3000
Recommended Torque	M8:25 M12:75 M20:400 M24:675 M30:1350
Metallurgy	Stainless Steel
Excitation	5 – 12 vdc
Safe Load Limit	150 % Emax
Ultimate Load	300 % Emax
Protection Class	IP67
Compensated Temp	-10 to +40 °C
Operating Temp	-35 to +65 °C
Storage Temp	-40 to +70 °C
Warranty	Two years
