Honeywell / Model 2110-2116 Flanged Reaction 토크센서

• High torsional stiffness
• Higher resistance to bending moments
• Reduced friction error
• Low-end sensitivity due to absence of
moving parts

Safety considerations: It would be unsafe to operate Honeywell torque sensors and load cells beyond static overload or ultimate extraneous load limits as defined in the glossary of terms or, when applicable, higher than maximum speed. When in doubt, consult factory. Honeywell is not responsible for any property damage or personal injury which may result because of the misapplication of the transducer.

Category:
브랜드:

설명

Honeywell Model 2110-2116 Flanged Reaction Torque Sensor

Order codes

2110 Model 2110 flanged reaction torque sensor, 2000 lb-in to 5000 lb-in
2111 Model 2111 flanged reaction torque sensor, 10000 lb-in to 30000 lb-in
2112 Model 2112 flanged reaction torque sensor, 50000 lb-in to 100000 lb-in
2113 Model 2113 flanged reaction torque sensor, 200000 lb-in
2114 Model 2114 flanged reaction torque sensor, 300000 lb-in to 500000 lb-in
2115 Model 2115 flanged reaction torque sensor, 600000 lb-in to 750000 lb-in
2116 Model 2116 flanged reaction torque sensor, 1200000 lb-in to 2400000 lb-in

Specifications

Category Parameter Specification
Performance Torque range 2000 lb-in to 2,400,000 lb-in
Non-linearity ±0.1 % of rated output
Hysteresis ±0.1 % of rated output
Repeatability ±0.05 % of rated output
Output @ rated capacity 2 mV/V (nominal)
Environmental Operating temperature -54 °C to 93 °C [-65 °F to 200 °F]
Compensated temperature 21 °C to 77 °C [70 °F to 170 °F]
Temperature effect, zero ±0.002 %/of rated output °F
Temperature effect, output ±0.002 %/of reading °F
Electrical Excitation (maximum) 20 Vdc or Vac RMS
Insulation resistance > 5000 MΩ @ 50 Vdc
Bridge resistance 350 Ω (nominal)
Number of bridges 1
Zero balance ±1.0 % of rated output

Mechanical Specifications

Model Capacity Nm [lb-in] Overload Nm [lb-in] Torsional stiffness Nm/rad [lb-in/rad] Max. overhung moment WxS Nm [lb-in] Max. shear W N [lb] Max. thrust P N [lb]
2110-2K 225 [2000] 340 [3000] 43384 [384000] 113 [1000] 6675 [1500] 8895 [2000]
2110-5K 565 [5000] 845 [7500] 103941 [920000] 226 [2000] 8896 [2000] 13344 [3000]
2111-10K 1130 [10000] 1690 [15000] 302784 [2680000] 565 [5000] 17800 [4000] 26688 [6000]
2111-20K 2250 [20000] 3380 [30000] 649630 [5750000] 1130 [10000] 28900 [6500] 44480 [10000]
2111-30K 3390 [30000] 5085 [45000] 1129790 [10000000] 1695 [15000] 38630 [8500] 57824 [13000]
2112-50K 5650 [50000] 8475 [75000] 903833 [8000000] 2704 [24000] 53375 [12000] 80064 [18000]
2112-100K 11300 [100000] 16950 [150000] 2259584 [20000000] 5650 [50000] 89000 [20000] 133440 [30000]
2113-200K 22600 [200000] 33900 [300000] 3773505 [33400000] 10170 [90000] 133440 [30000] 177920 [40000]
2114-300K 33900 [300000] 50850 [450000] 6778752 [60000000] 16950 [150000] 186800 [42000] 266880 [60000]
2114-500K* 56500 [500000] 84750 [750000] 12879628 [114000000] 22600 [200000] 244640 [55000] 355840 [80000]
2115-600K* 67796 [600000] 101695 [900000] 18079096 [160000000] 22600 [200000] 422560 [95000] 400320 [90000]
2115-750K* 84745 [750000] 127119 [1125000] 23728814 [210000000] 28250 [250000] 489280 [110000] 467040 [105000]
2116-1200K* 135593 [1200000] 203375 [1800000] 20338983 [180000000] 39550 [350000] 622720 [140000] 578240 [130000]
2116-2400K* 271186 [2400000] 406800 [3600000] 48587570 [430000000] 79096 [700000] 1000800 [225000] 934080 [210000]

Typical system diagram

Mating Connectors & Cables

064-LW13621 Mating Connector
7200-76-XX* Mating connector & 6 conductor cable
(unamplified unit with sense leads but not shunt cal)
7200-75-XX** Mating connector & 4 conductor cable
(unamplified unit without sense leads but not shunt cal)
7200-111-XX* Mating connector & 6 conductor cable
(for connection to instrument 7541)
7200-110-XX** Mating connector & 4 conductor cable
(for connection to instrument 7541)
* XX represents length in feet 100ft maximum
** XX represents length in feet 20ft maximum

Load carrying capacity

Mounting dimensions and characteristics

Model C cm [in] D cm [in] F cm [in] G* cm [in] H cm [in] N cm [in] J** cm [in]
2110-2K, -5K 7.62 [3] 10.16 [4] 8.26 [3.25] 3.81 [1.50] 0.32 [0.13] 1.27 [0.50] 0.83 [0.33]
2111-10K, -20K 8.89 [3.50] 12.70 [5] 10.80 [4.25] 5.08 [2.00] 0.64 [0.25] 1.91 [0.75] 0.99 [0.39]
2112-50K, -100K 18.73 [7.38] 20.32 [8] 16.51 [6.50] 8.89 [3.50] 0.79 [0.31] 3.81 [1.50] 1.63 [0.65]
2113-200K 21.59 [8.50] 24.77 [9.75] 20.32 [8] 10.16 [4] 0.79 [0.31] 3.81 [1.50] 1.94 [0.77]
2114-300K, -500K**** 26.67 [10.50] 35.63 [14] 27.94 [11] 15.24 [6] 0.79 [0.31] 5.08 [2] 2.59 [1.02]
2115-600K, -750K**** 26.67 [10.50] 38.10 [15] 30.48 [12] 15.24 [6] 0.79 [0.31] 5.08 [2] 3.85 [1.52]
2116-1200K, -2400K**** 40.64 [16] 50.80 [20] 40.64 [16] 20.32 [8] 1.27 [0.50] 5.08 [2] 3.86 [1.52]***

* Tolerance on shaft diameter +0.002 – 0.00
** Eight equally spaced holes are located within 0.005 in of true position
*** 16 equally spaced holes
**** Calibration performed to 300000 lb-in max.
