Performance Features

• Compression ring force sensor for measurement of
clamping forces
• TEDS (Transducer Electronic Data Sheet)
Standard IEEE 1451.4 (optional)
• Measuring washer
• Low measuring range, very high natural frequency
• Stainless steel
• Level of protection IP65
• Long-term stability
• Simple handling and assembly
• Special versions on request

Application

• Equipment engineering
• Automotive industry
• Measuring and control devices
• Fully automated machining centres
• Tool engineering
• Special mechanical engineering
