Thread Friction Sensor M-1902 with Rated Thread Friction Torque of 100 N·m / Rated Screw Head Friction Torque of 100 N·m and Rated Pre-Load of 100 kN
Lorenz / Thread Friction Sensor M-1902
Performance Features
• Thread friction sensor for measuring of pre-load, friction
torque underneath the screw head and thread friction
torque
• EDS (Transducer Electronic Data Sheet)
Standard IEEE 1451.4 (optional)
• High torsional stiffness
• Simple handling and assembly
• Special versions on request
Application
• Assembly technology
• Process measuring and control technology
• Automotive industry
• Measuring and control devices
• Tool engineering
• Special mechanical engineering
